Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon

    Buy cheap Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon from wholesalers

    Buy cheap Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon from wholesalers
    • Buy cheap Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon from wholesalers
    • Buy cheap Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon from wholesalers
    • Buy cheap Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon from wholesalers

    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon

    Ask Lasest Price
    Brand Name : SHANGWEN
    Model Number : SW6AJ-T
    Price : $1.65 - $2.05/pieces
    • Product Details
    • Company Profile

    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon


    Outdoor Dustproof Waterproof 7 Pin Power Connector For Audio And Video Connection

    Products Description
    Power connector series-7 core male powercon(card buckle type)
    This series is widely used in audio and video connection, lighting, LED display, industrial equipment and other industries.
    The enclosure is made of industrial PBT insulation material, which is resistant to pressure, high temperature, corrosion and flame retardant up to UL94-V0.
    The inner core is made of copper alloy, which has strong contact stability and can strengthen the control of temperature rise.
    The materials used in this series are extremely elegant, and the design of many inner cores meets the diversified industrial needs. Not afraid to apply in all kinds of bad conditions!
    Model : SW6AJ-T ( outdoor use )

    ☑Adopt one key press button locking method,plug and play,fast and convenient;
    Adopt high-strength structural materials, pressure-resistant structure design,can
    withstand greater vibration and shock.
    High-power industrial waterproof connector - waterproof, moisture-proof and dust proof

    ☑The insulating parts of the shell are high-performance engineering plastics, and the flame retardant grade reaches UL94-V0
    The connector is plated with gold/silver beryllium copper, which is oxidation and corrosion resistant to ensure fast signal
    transmission and electrical conductivity
    Multi-style inner core design to meet the needs of various industries

    ☑Precision waterproof design,with high waterproof level,no fear of wading environment;
    ☑Connection mode:

    1. Screw clamping and welding
    2. Lock the cable with screws
    ☑Protection level: used in outdoor scenes, protection level up to IP65/IP67
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof PowerconOutdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon

    1. Electrical parameters
    Contacts NO.
    Φ1.0* 6 pin
    Rated current
    10A
    Rated voltage
    250V AC
    Contact resistance
    ≤4mΩ
    Dielectric strength
    1500V AC
    Insulation resistance
    >1000MΩ
    2. Mechanical parameters
    Service life
    >1000 times
    Power line
    0.5mm²
    Wire stripping length
    5-7mm
    Type of teminals
    Soldering
    3. Material and environmental parameters
    Shell&insulated parts
    PBT
    Contacts
    Brass with gold-plated
    Sealing
    Silicone/rubber
    Flame-retardant grade
    UL94-V0
    Temperature range
    -25°C to +85°C
    Temperature rise
    Temperature rise < 30º at 20A, < 40º at 25A, < 50º at 30A
    Protection level
    IP65
    4. Size reference (unit /mm)
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    5. Installation reference drawing
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    Application area
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    Company Information
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    Patent & Certification
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    Exhibition activities
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    Packaging reference
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    Payment and logistics
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    FAQ
    Outdoor 7 Pin IP67 Power Connector Dustproof Waterproof Powercon
    1. Why do we choose SHANG WEN supply?
    A:We promise:All of our products are power regulated.The output voltage and current are true one.all with good quality and competitive price.We assure you timely delivery by keeping 80% standard products inventory and best after-sale service.All have done 100% long time ful-load aging test/ burn-in test before shipment.

    2. What is the applicable range of this product?
    A:Suitable for fixed & rental installation display screen, stage lighting and sound, security, new energy, medical etc.

    3. Can your products pass CE/ROHS certificate?
    A:Yes,our products meet the industrial standards,like:CE/UL/RoHS/CCC.

    4. Accept sample order ?What is your minimum order quantity?
    A:Trial order or sample order is accept,but same cost as bulk.

    5. What are the shipping ways you can offer?
    A:By air/sea according to customers'requirements.

    6. Do your products come with warranty?
    A:Yes,we promise 1-3 year warranty according to different model.
